Sony PXW-X320 1/2" multi codec broadcast shoulder camera, incl. 16x zoom lens

he PXW-X320 is a high-performance SxS memory camcorder which inherits field-proven operability from the reputable PMW-320. The PXW-X320 has become a part of the XDCAM HD422 family, comes equipped with cutting-edge imaging technology – three 1/2-inch-type Full-HD Exmor CMOS sensors with an extremely high S/N ratio – with Flash Band Reducer feature to provide outstanding picture quality.

The PXW-X320 supports XAVC offering high quality content creation in the HD domain. In addition to XAVC, MPEG HD422, MPEG HD, MPEG IMX, and DVCAM are supported. Two HD/SD-SDI, HDMI, i.LINK™, and composite outputs provide a wide range of AV and IT interfaces. The PXW-X320 also supports wireless operation using an optional adapter, the CBK-WA101. This enables easy and quick clip data transmission to broadcast stations, saving the time and transportation cost of shot clip delivery.

With various functions inherited from Sony’s world-acclaimed XDCAM camcorders and yet highly cost effective with lens included, the PXW-X320 is an ideal choice for many different camera professionals, from those engaged in news gathering, when speed is the key concern, to those who produce TV programs and documentaries, when quality is crucial.

High picture quality recording on SxS memory cards
Offer high resolution, high sensitivity (F11 at 59.94 Hz / F12 at 50 Hz), low noise (60 dB), and a wide dynamic range.

Selectable format and bit rates
Includes Full HD (1920 x 1080) 59.94i/50i/29.97p/25p/23.98p and HD (1280 x 720) 59.94p/50p, as well as XAVC Intra at 100 Mbps, XAVC Long at up to 50 Mbps, MPEG HD422 at 50 Mbps, MPEG HD at up to 35 Mbps, MPEG IMX at 50 Mbps and DVCAM at 25 Mbps.

Variety of interfaces
Interfaces include 2 x SD / HD-SDI, HDMI, USB and i.Link.

1/2" sensor
LC Display with viewfinder (960x540 pixels)
Incl. 16x Fujinon zoom lens
3D noise reduction
Signal to noise ratio: 60 dB
Sensitivity: 11 stops
Built-in Flash Band Reducer reduces flicks in images caused by flashes
Recording in codecs MPEG2 HD422 (50 Mbit/s), HD420(35 Mbit/s), MPEG IMX, DVCAM, XAVC Intra and Long GOP
Use of Wifi adapter CBK-WA101 possible (not included in delivery)
Faster workflow thanks to File Transfer (FTP push) or Live Streaming (QoS and non QoS)
Convertable to a system camera with the digital triax adapter CA-TX70 or the fibre adapter CA-FB70 with CBK-CE01 option (not included in delivery)

Brochure e datasheet

• BROCHURE: PXW-X320
