Hypex UcD400 Stereo Amplifier 2x 200 watts

UcD400KIT

New

Hypex UcD400 2x 200 watt stereo amplifier with XLR inputs with Hypex UcD400 modules, high performance stereo amplifier based on Hypex's UcD400HG HxR modules, stereo amplifier, very low distortion over the entire frequency range, neutral and transparent reproduction, form factor reduced

More details

In Stock

€ 649,00
€ 531,97tax excl.

Add to my wishlist

The UcD technology is a high performance and reliable amplifier technology. The UcD amplifier modules stand out in our amplifier modules category, due to their unique circuit topology. They have a flat frequency response irrespective of load impedance, nearly frequency-independent distortion behavior and very low radiated and conducted EMI.



Are two UcD400HG HxR amplifier modules, SMPS400A400 power supply and a black anodized aluminum case. The amplifier modules and power supply combination enable high and reliable performance from the UcD technology. The black anodized case provides good heat dissipation, protection and a small form factor.



Along the main parts, this kit includes everything else you need to build a powerful high-quality monoblock amplifier. Assembly is easy and only requires proper positioning of the modules, bolts to be tightened and connectors to be clicked. Anybody comfortable with a screwdriver can build this amazing stereo amplifier.



Specifications

Rated power output 2x 400 watts at 4 ohms
2x 200 watts at 8 ohms
Minimum load 1 ohm
Efficiency 92 %
Signal-to-noise ratio (SNR) -
Distortion 0.01 % THD+N (20-20,000 Hz at 0.5 x rated power output)
Frequency response 10 - 50,000 Hz
Gain 26 dB
Input sensitivity -
Input impedance 100k ohms
Circuit Topology UcD®
Speaker output channels 2
Input connection type XLR
Speaker output connection type Binding posts
Power Requirements 110 / 230 VAC (jumper selectable)
Power inlet connector IEC C14
Current limit 20 A
Under/over voltage protection check
Dimensions (L x W x H) 280 x 200 x 78 mm


What’s In The Box

  • Ready to use Stereo 2x UcD400HG HxR amplifier
  • SMPS400A400 switch mode power supply
  • Aluminum enclosure
  • IEC C14 power connector (including fuse)
  • IEC C13 power cable
