Allen & Heath Avantis 22X 64 Channel / 42 Buses / 96 kHz Digital Mixer

Avantis' power comes from the XCVI Core, pioneered by Allen & Heath's R&D team using next-generation FPGA technology, with parallel virtual processing cores generating enough power for 88× processing channels 42 (including FX returns) at a sample rate of 96 kHz.

The enormous power of XCVI (25 billion operations per second) allows Avantis to provide 64 full processing inputs and 12 stereo FX returns, 42 buses with configurable mix architecture, variable bit depth for maximum precision and noise performance , virtually infinite mix headroom thanks to a 96-bit accumulator and class-leading latency at an ultra-low 0.7 ms.

• 96kHz digital mixer 64 channels / 42 buses

• XCVI FPGA core with ultra-low latency (0.7 ms)

• Fully configurable mix bus architecture

• Super resistant full metal frame

• Continuity UI seamlessly links physical and touchscreen controls for faster, more intuitive workflows

• dPack option adds dLive processing, including 16 Dyn8 engines, plus zero-latency DEEP compressors per channel and dual-stage tube preamp

• 12 RackExtra FX slots with dedicated stereo returns

• 16 DCAs

• Dual 15.6" Full HD capacitive touchscreen with gesture control

• AMM (Automatic Mic Mixer) up to 64 channels on 1, 2 or 4 zones

• Fully assignable layout

• 144 fader strips (24 faders, 6 layers) with optional dedicated master section

• SLink port for connecting to remote I/O expanders and ME Personal Mixing System

• 12 analog XLR inputs / 12 analog XLR outputs

• 1 stereo AES input / 2 stereo AES outputs

• 2 I/O ports, both capable of running 128x128 at 96kHz - for included option cards. Dante, MADI and gigaACE

• User configurable rotary controls

• 24 assignable softkeys

• Comprehensive measurement with multi-point peak detection

• Internal memory for stereo playback and recording

• USB stereo playback

• BNC Word Clock
