Blackmagic Design StudioBridge 100G

Name: Blackmagic Design StudioBridge 100G
Brand: Blackmagic Design
SKU: CONVNVIPR/SBD100X2
Price: 2726.7 EUR
Availability: PreOrder

Blackmagic Design StudioBridge 100G, Bridge 1 or 2 Channels of 4K60 Video 2 x 100GbE Camera Feed Inputs, Dual Redundant 100GbE Video Outputs, SMPTE 2110 IP Video Compliance, 2.2" LCD Monitor & Control Knob/Buttons, 2 x RJ45 & 2 x SFP Accessory Ports, External Control via 1GbE RJ45 Port, 16 Channels of Embedded Audio per Stream, 1 RU Form Factor, Dual Redundant AC Power Inputs

The Blackmagic Design StudioBridge 100G is a 1 RU IP video bridge designed to integrate one to two high-bandwidth camera streams into redundant 100G broadcast infrastructures. Supporting up to two channels of SMPTE 2110 video at resolutions up to 4K60, the unit converts one 100GbE IP video stream or two IP video streams of less than 100Gb/s total bandwidth into dual 100GbE QSFP28 outputs with SMPTE 2022-7 redundancy for uninterrupted signal delivery. Each input supports automatic format detection across HD and Ultra HD standards, along with 16 channels of embedded audio per stream, ensuring compatibility with modern IP-based production workflows.

Engineered for deployment in live production and broadcast environments, the StudioBridge 100G sports two 10G RJ45 ports and two 10G SFP optical fiber interfaces for additional accessory connection. A front-panel 2.2" LCD with integrated control knob and buttons allows real-time monitoring of video, audio, and system status, while built-in speaker and headphone output provide immediate audio confidence monitoring. External control is supported via a dedicated RJ45 for NMOS-based configuration and USB-C for setup and firmware updates, with dual IEC power inputs ensuring power redundancy for reliable performance.

IP Video Bridging

Convert one to two camera feeds under 100 Gb/s total bandwidth into dual 100GbE outputs
Two 100GbE QSFP28 inputs and two 100GbE QSFP28 outputs with SMPTE 2022-7 redundancy
Supports SMPTE 2110-20, 2110-21, 2110-30, and 2110-40 standards
Auto-detection of HD and Ultra HD formats up to 4K60
10-bit 4:2:2 video with Rec. 709 and Rec. 2020 color space support
16 channels of embedded audio per IP video stream

Convenient Design

2.2" front-panel LCD for video, audio, timecode, and system monitoring
Integrated control knob and buttons for source selection and configuration
Built-in speaker and headphone output for audio monitoring
Two RJ45 and two SFP optical fiber accessory connectors
Dedicated RJ45 port for NMOS control, configuration, and updates
USB-C interface for firmware updates and local configuration
Dual IEC C14 AC inputs for redundant power delivery

Items Included

Blackmagic Design StudioBridge 100G

Reference CONVNVIPR/SBD100X2
