Kiloview Kilolink Station PRO All-in-One 4K HDMI & 3G-SDI Hardware Bonding Receiver

Your All-in-One Broadcast Ready Hardware Bonding Receiver & Device Management Platform - Say Goodbye to Server Complexity & Ongoing Costs!

Professional, Powerful, and Cost-Effective

KiloLink Station PRO is Kiloview's dedicated hardware designed for professional wireless bonding reception, centralized device management, and high-quality IP/SDI workflows. By integrating the full capabilities of KiloLink Server Pro into a compact, half-1RU appliance, it delivers a true plug-and-play experience.

Forget complex server deployments, recurring cloud costs, or Linux environment optimizations. Whether you are managing multi-camera field reports, educational broadcasts, or mission-critical enterprise video, KiloLink Station provides synchronized reception, flexible outputs, and intuitive control in one reliable system.

Plug-and-Play: Professional Bonding with Zero Setup

KiloLink Station comes pre-configured with KiloLink Server Pro. It can register KiloLink-enabled devices the moment they power on. No Docker, no commands, and no technical hurdles-just instant, secure connectivity that gets your workflow operational in minutes.

8-Channel High-Performance Wireless Bonding

Designed for the field, the system supports simultaneous reception from up to 8 P3 or P3 Mini wireless bonding encoders. Powered by Kiloview's patented KiloLink technology, it ensures stable transmission across multiple cellular links, even in the most challenging network environments.

Visualized Network & Unified Management

When paired with Kiloview's AVX Media Hub, KiloLink Station offers a Visualized Topology View, allowing you to monitor device health, connectivity, and signal flow in real-time.

Multi-Protocol Versatility

KiloLink Station supports a comprehensive suite of protocols- NDI HX, SRT, RTMP, RTP/RTSP, and HLS. This versatility allows you to convert video streams coming from Kiloview wireless encoders P3 or P3 mini to any other IP protocols to fit your specific workflow, whether it's for live streaming, remote point-to-point transmission or NDI production.

Applications:

• Broadcast & News

• Sports & Live Events

• Education & Campus

• Remote Production

Features:

Subscription-Free

Built-in professional SSD storage. record every incoming stream locally.

Dual-NIC Redundancy

Compact Half-1RU

API for Easy Integration

User-Friendly Interface

24/7 Stability

API for Easy Integration

3.5mm Audio Line Out

Multiview Layout

Specifications:

Memory: 16GB DDR4

Storage: 128GB eMMC

Streaming Protocols: NDI HX, SRT, RTMP, RTP/RTSP, UDP and HLS

Video Decoding: H.264/H.265

Bonding Performance: Supports up to 8x P3 units simultaneously.

Video Output:

- 4x 3G-SDI (Pro Edition Only): Up to 1920*1080p60 (Downward compatible, includes 1080i50 support)

- 1x 4K HDMI: Up to 4KP60 (Downward compatible)

Encoding Performance: Simultaneous Encoding: 4x units x 5 streams each.

Max Performance:

- 4K P60 AVC/HEVC 200Mbps @ Level 5.1 Main Tier

- ITU-T H.264 High/Main/Baseline Profile @ Level 5.2

Audio Decoding: AAC

Audio Output: 1x 3.5mm Line Out

Multiview Layout: Supports up to 4-way split screen (Quad-view)

Network:

- 1x 5GbE RJ45 Ethernet

- 1x 1GbE RJ45 Ethernet

Power Supply: DC 12V 3A

Power Consumption: ≤12W

Environment:

- Operating Temp: 14°F - 122°F (-10°C - 50°C)

- Storage Temp: -4°F - 158°F (-20°C - 70°C)

Relative Humidity: 5% - 90% (non-condensing)(Pending final testing)

Management: Web-based UI Management

Dimensions: 9.11" x 8.66" x 1.73" (220mm x 231.45mm x 44mm)(Compact half-1RU; two units can be rack-mounted as 1RU)

Weight: 3.92lbs (1780g)

Item Includes:

1x Kiloview Kilolink Station PRO
