HDL-MULTIP3G/04HD
New
Blackmagic Design MultiView 4 HD, 4 x SD/HD/3G-SDI Inputs1 x SDI & 1 x HDMI Outputs, Automatic Signal Detection, SDI Re-Clocking on Output, Monitor EDID Support, Display Custom Labels & Audio Metering, Compact Metal Housing, Quad Multiviewer
Out of Stock - Normally ships in 10/15 days
Warning: Last items in stock!
Availability date:
Blackmagic Design MultiView 4 HD
Blackmagic Design MultiView 4 HD, 4 x SD/HD/3G-SDI Inputs1 x SDI & 1 x HDMI Outputs, Automatic Signal Detection, SDI Re-Clocking on Output, Monitor EDID Support, Display Custom Labels & Audio Metering, Compact Metal Housing, Quad Multiviewer
Recipient :
* Required fields
or Cancel
The Blackmagic Design MultiView 4 HD is a compact mini-converter that enables you to display up to four separate SDI streams via its HDMI or 10-bit SDI multiview outputs. This unit supports SD/HD/3G-SDI formats, and features automatic signal detection, SDI re-clocking, and monitor EDID support.
Each view can display custom overlays like labels and audio meters, and the integrated USB 2.0 interface can be used for updates. The MultiView 4 HD's metal housing measures approximately 5.3 x 3.6", and it includes a power supply with international adapters.
Features
Four SDI inputs output to one SDI and one HDMI multiview
Automatic signal detection, SDI output re-clocking
Monitor any combination of HD or SD formats, and frame rates
Display custom labels, audio metering, and more on each view
Specs
Connections | |
---|---|
Inputs | SD/HD/3G-SDI: 4 x BNC |
Outputs | SD/HD/3G-SDI: 1 x BNC, 10-bit HDMI: 1 x Type A |
Standards | |
---|---|
Supported Video Standards | 2K DCI: 1080p: 25/24/23.98 HD: 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080PsF: 24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 NTSC SD: 525i: 59.94 PAL SD: 625i: 50 |
SDI Compliance | SMPTE 425M-B/310M/296M/292M/259M ITU-R BT.656/BT.601 |
SDI Color Precision | 10-bit 4:4:4, 4:2:2 |
SDI Color Space | Inputs: YUV, RGB Output: YUV |
SDI Video Sampling | 4:4:4, 4:2:2 |
SDI Audio Sampling | 24-bit, 48 kHz |
SDI Metadata Support | SMPTE 352M |
Operating System Support | |
---|---|
Compatible Operating Systems | MacOS 10.12 Sierra MacOS 10.13 High Sierra, or later Windows 8.1, or 10 |
